Chemical Dosing System
The quantitative chemical is placed in stirring solution tank for stirring and dissolving. After full dissolution, the chemical will be pump to certain working point by the metering pump, and the amount of chemical can be adjusted to meet various chemical requirements.
Description
LK-JYQ Chemical Dosing System Reagent Preparation Station
Overview
| LK-JYQ Chemical Dosing System is using metering pump as the main feeding device, equip with solvent tank, stirrer, level gauge, safety valve, check valve, pressure gauge, a filter, buffer, pipes, valves, base, Escalators, automatic monitoring systems, power control systems, to form simple dosing devices depends on different applications. The quantitative chemical is placed in stirring solution tank for stirring and dissolving. After full dissolution, the chemical will be pump to certain working point by the metering pump, and the amount of chemical can be adjusted to meet various chemical requirements. |  |
Features
●Various capacity as custimized; |
●Easy Operation,PLC control system; |
●More economical dosing system; |
●Good option for different chemical application,anticorrosive to most chemicals. |
Parameters
| Model | Ability to bubble medicine（L/h） | Physical dimension(mm) | Power（KW） | Weight（kg） | ||
| D | H | no load | run | |||
LK-JYQ-500 | 500 | 800 | 1470 | 0.55 | 26 | 526 |
LK-JYQ-1000 | 1000 | 1050 | 1570 | 0.75 | 35 | 1035 |
LK-JYQ-1500 | 1500 | 1200 | 1840 | 0.75 | 60 | 1560 |
LK-JYQ-2000 | 2000 | 1320 | 2090 | 1.5 | 70 | 2070 |
Onsite working reference
